Thermal profiling is the recording of time and temperature throughout a thermal process – most often to measure exposure within an oven. Used in many industries, thermal profiling collects data on a product’s thermal transformation experience, which is then analyzed to optimize complex process settings and conditions to ensure quality results.

A pioneer in the design of the traveling thermal profiler, ECD has developed a suite of thermal data logging products that serve the electronics, baking, industrial and solar industries, among others.

With a revolutionary new design, M.O.L.E.™ EV6 brings deep data collection and touch screen convenience to thermal profiling. The traveling thermal profiler allows configuration, measurement and data analysis right on the device – providing immediate actionable information, saving time and reducing the requirement for intensive operator training.

Using a familiar smartphone-like capacitive touch screen, users now have shop floor data literally at their fingertips. The six-channel M.O.L.E. EV6 integrates with all ECD RIDER™ machine quality management technologies for a truly scalable approach, made easier with visual, touch screen control.

Do you demand the highest density of thermocouple placement possible on your Hi-Reliability, High-Value PCB? ECD’s got your Spec! Do you expect a software package that flexes with your workflow, providing customizable data extractions, Imports of your .MDM M.O.L.E. libraries and compatibility with your intranet, Excel, and all ECD M.O.L.E.™ Profilers?

MEGAM.O.L.E.™ 20 delivers your specifications in a sleek 7.2mm thin package with patented productivity enhancing features that will give you the edge in R&D decision making to WOW. Management, Customers and your OEM-EMS QA linkage.

The V-M.O.L.E.™ is a full-featured compact thermal profiler that belies its sophistication in an easy-to-use 3-channel Mini-thermocouple configuration. Ideal for VERIFICATION of PCB profile performance, 3 channels give you Hot, Cold and Sensitive component data for verifying the correct oven settings.

V-M.O.L.E. also boasts the same powerful MAP software created for the MEGAM.O.L.E.™ 20 thermal profiler, including the Target-10 feature, and of course, the patented “OK-Button” The world’s only one-touch Go/No-Go indicator of profile compliance to pre-programmed specifications.

Thermal profiling is the recording of time and temperature throughout a thermal process – most often to measure exposure within an oven. Used in many industries, thermal profiling collects data on a product’s thermal transformation experience, which is then analyzed to optimize complex process settings and conditions to ensure quality results.

The spectral output from an UV LED source is narrow or monochromatic when compared to broadband (mercury) source. Each of EIT 2.0 LLC’s L-Bands (L-365, L-385, L-395 and L-405) has an optic response and dynamic range optimized for LEDs. Our patented Total Measured Optic Response in which ALL optics in the instrument are included in the instrument response result in better performance and repeatability; unit-to-unit, run-to-run and source-to-source.

Online Monitoring allows users to continuously monitor and track a UV source. This is useful in applications where a radiometer will not fit, where high value and/or high production speeds are used and when it is not practical or easy to access each lamp (multi-lamp bank and/or elevated). The feedback is relative and looks at the relative output over time. Online Monitoring will identify both gradual (aging lamps) or sudden (equipment malfunction, user changed parameters) changes in the intensity.

Radiometers provided calibrated irradiance (W/cm²) and energy density values (J/cm²) in one to four bands. Profiling Radiometers also provide the irradiance profile (W/cm² as a function of time) which is useful to further understand the UV conditions and compare UV systems.

Equipped with the most modern, accurate systems that drive and steering technology offers today. Mediums rarely behave the same way, environmental conditions are significant for the behavior of liquid changes. This is why there is virtually no standard application in dispensing. Specific solutions for each dispensing task depending on both environmental influences and the type of liquid have to be evaluated. Easy programming and operation allow for a wide range of dispensing applications.

FoxSign fully understands that our success is attributable to our customers and the society to which we all belong. As a global citizen, FoxSign is determined to make significant contributions to society various accessible process equipments through the experiences and technical abilities we already have.

Our service covered 4 main Deflash processes:

1. Electrolysis Deflash – ED
2. Chemical Deflash – CD
3. Water Jet Deflash – WJ
4. Wet Blasting Deflash – WB

The GAR1200 is an in-line router machine specially designed to route (depanelize) large panels with PCB size up to 350mm x 310mm into individual units. It is a fast, space-saving, and accurate machine designed for high volume production with minimal operator participation. It has two worktables. While one of the worktables is in high-speed routing operation, the other worktable works with the robotic P&P module to unload boards and load the new PCB panel. This gives us 100% operational uptime without the issue of load/unload time. Using a high-resolution CCD camera and GAR user-friendly Windows-based software allows users to program the routing paths in minutes. There are also no limitations in the number of programs stored. GAR1200 uses high-quality components and a welded steel structure to ensure rigidity and high performance. All the axes and linear guides used are protected from dust and dirt to increase lifespan and performance.

The RBM is a sophisticated and versatile fully-automated dual station de-panelling system. It is fitted with an auto conveyor width adjustment feature and also has various other tools to optimise the routing process based on your workflow.

The GSR series standalone routers are designed to be high performance and cost-effective solutions to meet your PCB depaneling requirements. The system allows continuous routing without stoppages and has a user-friendly software that allows the user to program the routing paths within minutes. Key components are protected from dust and dirt to increase machine performance and lifespan.
